| Place of Origin: | China |
|---|---|
| Brand Name: | Jufu |
| Certification: | ISO9001 |
| Model Number: | JFRO-180T |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Export standard wooden box (like plywood), no need to fumigate, really suitable for shipping. |
| Delivery Time: | 2-4 Weeks |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Item: | Pharmaceutical Water Purification System | Desalination Rate: | ≥99.5% |
|---|---|---|---|
| Power: | 0.37-75KW | Valve: | Automatic / Manual |
| Membranes Brand: | Dow, Hydranautics, Toray Or Vontron | Tank Material: | SS/FRP (optional) |
| Pipe Material: | U-PVC/C-PVC/Stainless Steel (optional) | After-sales Service: | Technical Support And Repair Service |
| Warranty: | 1 Year | Certilication: | ISO9001 |
| High Light: | 180TPH Pharmaceutical Water Purification System,EDI industrial reverse osmosis equipment,Pharma Water Purification System |
||
180TPH Two Stage RO Plant Pharmaceutical Industry EDI For High Purity Water
Description of Pharmaceutical Water Purification System
Pharmaceutical purified water has certain requirements for conductivity and ion content, etc. The primary water quality objectives are: conductivity ≤2 liters of s/cm, heavy metal ≤0.3 liters of g/LTOC≤500 liters of g/L.In order to reach the purified water quality requirements, the current primary choice of reverse osmosis.
Our medical purified water system uses bipolar reverse osmosis + EDI electrodeionization process, with high desalination rate, stable effluent quality and reliable performance, ensuring the stable operation of the system to a large extent.
Raw Water Quality Request
| Raw water quality | After RO treatment, conductivity< 30us/cm |
| PH | 7.5~9.0 |
| Temperature | 5~38℃ |
| Inlet water pressure | 0.2~0.5Mpa |
| Hardness(CaCo3) | < 0.5ppm |
| Organic matters | TOC<0.5ppm |
| Oxidizer | C12<0.05ppm;O3<0.02ppm |
| Silicon | <0.5ppm(SiO2) |
| Total CO2 | <3ppm |
| Particulates | < 1μm |
Equipment Process of Pharmaceutical Water Purification System
raw water → raw water pressure pump → multi-media filter → activated carbon filter → water softener → precision filter → first-stage reverse osmosis → PH adjustment → intermediate water tank → second-stage reverse osmosis (reverse osmosis membrane surface with positive charge )→Purification water tank→Pure water pump→UV sterilizer→Ozone generator→Microporous filter→Water point
Product Features
1. This system occupy little space, easy to operate, wide application range.
2. Reverse osmosis desalting rate ≥99%, machine desalting rate ≥97%. 98% of organic matters, colloids and bacteria can be removed.
3. Finished water under good electric conductivity, one stage ≤10μs/cm, two stage around 2-3μs/cm, EDI≤0.5μs/cm(based on raw water≤300μs/cm).
How Do Pharmaceutical Companies Choose Pure Water Equipment?
1. Pharmaceutical companies use a combination of ion exchange, reverse osmosis and ion exchange to obtain pure water, and then use distilled water to prepare water for injection. In the above-mentioned pharmaceutical water production process, ion exchange technology is still widely used as a means of deep desalination. However, when the ion exchange resin is regenerated, a large amount of waste acid and waste alkali will be produced, which will seriously pollute the environment and limit its development.
2. The removal rate of bacteria, pyrogens, viruses and organic matter in water by reverse osmosis membrane is 100%. Secondary reverse osmosis eliminates the use of ion exchange resins.
Pure water for medical use is stricter and more demanding.
1. It is often required that the resistance of ultrapure water should be higher than 15M. In order to ensure the safety of medical ultrapure water, the entire ultrapure water treatment equipment system is also composed of all stainless steel materials, and a sterilization device must be equipped before the water outlet.
2. Starting from the characteristics of ultra-pure water in the entire pharmaceutical industry, our company uses different technologies such as reverse osmosis and EDI to design different high-purity water treatment processes to meet the different requirements of high-purity water for different users.
Distilled Water for Pharmaceutical Application Areas
1. Production of large infusion, injection, oral liquid, etc;
2. Extraction, washing, injection and capsule production of API;
3. Eye drops and care solution production;
4. Hospital hemodialysis room, biochemical analysis room, operating room sterile water;
5. Multi-effect distilled water machine raw water, washing water;
6. Cosmetic process water, washing water;
7. Biochemical drug products, diagnostic reagents
FAQ
Q: What’s the type of your company? Manufacturer or Trading agent?
A: We’re the Hi-tech manufacturer in Water treatment industrial for almost two decades, we specialized in integrating Research & Development, Manufacturing, Sales, Engineering installation and Consulting on water treatment and water purification equipment and technologies.
Q: What kind of information need to be provided for product selection?
A: What ‘s the raw source of your water? If possible, please provide Water Analysis Report.
B: What’s your request on the output capacity of the equipment?
C: What’s the application for the project?
D: What’s the piping standard applied in your local market?
E: Do you need on-site installation guidance?
Q: How can I choose the products which can be perfectly match my case?
A: Tailor-made solutions will be provided by Jufu’s professional engineer based on your requirements.
All the pain-points of the project will be highlighted and solved for overall optimization.
